MU Optical Fiber Patch Cord LSZH High Strength Aramid Yarn Low Insertion Loss

Name: MU Optical Fiber Patch Cord LSZH High Strength Aramid Yarn Low Insertion Loss
Brand: FOCABLE
Price: 1 USD

Brand Name : FOCABLE

Model Number : MU SM Simplex Fiber Patch Cord

Certification : RoHS Compliant, SGS Certificate, ISO Certificate

Place of Origin : China

MOQ : 10PCS

Delivery Time : 3-5days

Packaging Details : 1PCS/PE Bag

Fiber Type : SM, OM1, OM2, OM3, OM4

Cable Material : PVC, LSZH, OFNP, OFNR, Hytrel

Cable Diameter : 0.9mm, 1.6mm, 1.8mm, 2.0mm, 2.4mm, 3.0mm

Connector : SC/APC, SC/UPC, FC/APC, FC/UPC, LC/APC, LC/UPC, ST, E2000, MU, MPO, MTRJ

Cores : Simplex, Duplex, 4cores, 6cores, 8cores, 12cores, 24cores, 48cores

Length : 1M, 2M, 3M, 5M or as per customer request

Contact Now

MU Optical Fiber Patch Cord LSZH High Strength Aramid Yarn Low Insertion Loss

The MU SM simplex fiber optic patch cord, these cables are with 9/125 single mode fiber, and connector types are PC, UPC or APC optional. The MU simplex single mode optical fiber patch cord are fully compatible with industrial standards; they are good prices, fast delivery and good looking and packing.

MU is the fiber optic connector invented by Lucent and it is small form factor connector suit for dense installations. MU has single mode and multimode versions, simplex or duplex, PC, UPC or APC. MU features compact, pull-proof design and RJ-45 style interface. Our MU optical fiber cord are compliant to IEC and EIA/TIA standards, they are compatible to use with equipment from other companies. We supply the MU fiber optic connectors, jumper cables, adapters, MU attenuators and related MU fiber optic components.

MU optical fiber patch cords are widely used in fiber optic systems; especially MU single mode products are very popular. MU standard fiber optic connectors are used for telecommunications, CATV, LAN, MAN, WAN, Test & Measurement, Industry, Medical and Sensors. MU fiber optic connectors comply with IEC 61754-13 & CECC 86 115-801 standards. They are well known for general, average applications. We supply single mode and multimode version MU fiber jumper cables and MU fiber optic components.

Features
Low insertion loss(≤0.20dB)and high return loss(≥55 dB)
Free-floating ceramic ferrule
UL-rated plastic housing and boot
Boots in a variety of colors
High precision alignment connector

Applications
Local Area Networks (LANs) and Wide Area Networks (WANs)
Fiber Optic CATV,FTTH,FTTB,FTTP etc
Fiber Optic telecommunication systems
Transmission Mode (ATM)
Fiber Optic Backbone
Military Instrumentation

SPECIFICATIONS

	Single mode	Multimode
Insertion Loss	Typical <=0.2dB, Maximum<=0.3dB	≤0.25dB
Return Loss	≥50 dB (PC) ≥60 dB (APC)
Repeatability	≤0.1
Durability	≤0.2 dB typical change, 1000 matings
Interchangeability	≤0.2dB
Tensile strength	>70N
Operating Temperature	-20 to + 70°C	-20 to + 70°C

ORDERING OPTIONS

Connector Color	Boot (cable) Size	Boot Color	Fiber Type	Cable number	Application	Length
Beige	0.9mm	Beige	9/125μm (SM)	Simplex	PC	Customized
Blue	2.0mm	Black	50/125μm(MM)	Duplex	APC
Green	3.0mm	Blue	62.5/125μm(MM)	Fan-out (4f)
		Green		Fan-out (6f)
		Gray		Fan-out (8f)
		Red		Fan-out (12f)
		White
